2D Fixed Mount Qr Code Barcode Scanner ES4560SR/ES4560HD
♦ Compact design and plug-and-play interfaces allow easy integration into different host devices
♦ Read all common 1D/2D barcodes from paper labels and electronic screens
♦ Megapixel image delivers better performance in decoding hard-to-read barcodes
♦ Advanced image induction technology ensures rapid induction of barcodes, even through a transparent lens in front of the scanning window
♦ Support external and serial trigger modes
♦ Soft white auxiliary lighting and green aiming cursor deliver comfortable and convenient scanning experience
♦ Pos payment
♦ Mobile coupons, tickets
♦ Ticket checking machine
♦ Microcontroller development
♦ Self-service terminals
♦ Mobile payment barcode scanning
| Physical Dimensions (L x W x H): | 52.3 mm x 49mm x 29mm |
| Weight: | 50g |
| Electrical Input voltage: | 5 VDC ±0.5V |
| Working: | 2.25 W (450 mA @ 5V) |
| Standby: | 1.25 W (250 mA @ 5V) |
| Host interface: | USB, RS-232 |
| Environmental | -10°C to 40°C (14°F to 104°F) |
| Operating temperature: | |
| Storage temperature: | ‘-40°C to 60°C (-40°F to 140°F) |
| Humidity: | 0% to 95%RH, no condensation |
| Drop: | Designed to withstand 1 m drops |
| Illuminance: | 0-100,000 Lux |
| Scanning Performance DPI: | 1280 x 800 pixel |
| Scan angle: | Horizontal: 47°; Vertical: 30° |
| Print Contrast: | 20% minimum reflectance difference |
| Pitch, Skew: +/-60°, +/-70° | |
| Decode Capability: | Reads standard 1D, PDF, 2D Symbologie |
