Xprinter XP-G480E Thermal Transfer Industrial Barcode Label Printer Optional WIFI Bluetooth
Developed for industrial environments and printing needs
Large Angle open cover design, easy to install consumables
Carbon tape capacity 600m, support 8-inch outer diameter label scroll bar
Supports a maximum label width of 120mm
Aluminum alloy casting body strong heat dissipation, industrial applications
Optional automatic stripping function, 128MB flash memory, expandable memory up to 4GB
Logistics & Warehousing: Shipping Label Printing, Inventory Management Tagging
Retail: Product Price Tagging, Shelf Labeling
Medical: Specimen Labeling, Patient Identification Badge Printing
Manufacturing: Component Part Labeling, Production Batch Tagging
Express Delivery: Package Label Generation, Route Indicator Printing
| Resolution | 300 DPI |
| Print Method | Thermal Transfer / Direct Thermal |
| Memory | 128 MB RAM / 128 MB Flash |
| Max.Print Width | 4.09 in./104 mm |
| Max.Print Speed | Up to 8 ips (203 mm/s) |
| Media Sensors | Movable Black Mark Sensor / Movable Gap Sensor |
| Emulation | TSPL, ZPL, EPL, DPL |
| Interface | USB+Serial+Lan, USB+Serial+Lan+Parallel+GPIO(Optional Wireless Connectivity: Bluetooth / Wi-Fi) |
| Display Screen | 3.5″ LCD, 320*480 pixel |
| Others | Optional RTC, Standard SD Card Slot |
| Media and Ribbon Characteristics | |
| Media Length | 0.39 in. ~ 35 in. (10 mm ~ 889 mm) |
| Media Width | 0.78 in. ~ 4.7 in. (20 mm ~ 120 mm) |
| Media Roll Size | 8 in./203 mm Outer Diameter, Core Inner Diameter: 1 in. (25.4 mm) |
| Media Thickness | 0.0023 in. (0.06 mm) Min.; 0.01 in. (0.254 mm) Max. |
| Media Types | Continuous, Gap, Black mark, Fan-fold, Perforated Media |
| Ribbon Outside Diameter | 3.58 in. / 91 mm |
| Max. Ribbon Length | 600 Meters (1968 ft.) |
| Ribbon Width | 0.78 in. ~ 4.3 in. (20 mm ~ 110 mm) |
| Ribbon Core l.D. | 1 in. / 25.4 mm |
| Environment Condition | |
| Operating Temp. | 5~40℃(41~104℉) |
| Storage Temp. | -40~60℃(-40~140℉) |
| Operating Humidity | 25 ~ 85% Non-Condensing |
| Storage Humidity | 10 ~ 90% Non-Condensing |
| Fonts/Graphics/Symbologies | |
| 1D Bar Codes | Code 39, Code 93, Code 128UCC, Code 128 subsets A, B, C, Codabar,Interleaved 2 of 5, EAN-8,EAN-13,EAN-128, UPC-A, UPC-E,EAN and UPC 2(5) digits add-on, MSI, PLESSEY, POSTNET, China POST, GS1 DataBar, Code 11 |
| 2D Bar Codes | PDF-417, Maxicode, DataMatrix, QR code, Aztec |
| Fonts and Graphics | Font 0 ~ Font 8 |
| Software | |
| Driver | Windows /Linux /Mac / Android / Chrome OS |
| SDK | Windows/Linux / Android /iOS |
| Software | Bartender UltraLite / Mobile Label Design App |
| Accessories | |
| Standard Accessories | Power Cord, USB Cable, User Manual, CD, Ribbon Spindle*2, Ribbon For Test, Ribbon Paper Core, Label Roll For Test |
| Factory Installed Options | Bluetooth Module, Wi-Fi Module, Peel-off Module, Cutter Module |
| User Options | 8″ External Paper Roll Holder |
| Product Warranty | |
| Printhead life | The earlier of 30 km usage or 1 year |
| Platen roller life | The earlier of 30 km usage or 1 year |
| Printer Warranty | 1 Year |
| Physical Characteristics | |
| Dimension | 504 mm × 257 mm × 297 mm (D × W × H) |
| Weight | 11 Kg |
