IDPRT IT4S 4 Inch Thermal Transfer Desktop Barcode Label Printer Opention Bluetooth WIFI
Better printing quality suitable for Wax and Resin ribbon.
Large memory for downloading True type fonts and label formats.
Dual printing method Direct thermal and Thermal transfer.
Able to install cutter module and peeler module.
Logistics and Warehousing
Agriculture Sector
Retail Industry
Medical Industry
Manufacturing Industry
|
Model
|
iT4S
|
|
|
Printing
|
Printing Method
|
Thermal transfer/Direct thermal
|
|
Resolution
|
203dpi/300dpi
|
|
|
Max.Printing Speed
|
5 ips (203dpi)
|
|
|
4 ips (300dpi)
|
||
|
Max.Printing Width
|
108 mm(203dpi),106 mm(300dpi)
|
|
|
Max.Pringting Length
|
2,286 mm(203dpi),1,524 mm(300dpi)
|
|
|
Memory
|
RAM
|
128 MB
|
|
Flash
|
256 MB
|
|
|
Detection
|
Sensor
|
Print Frame Open Detect, Ribbon End Detect, Paper Out Detect, TPH Over Heating Detect, 2 Fixed See-through sensor, Full Range
Reflective Sensor |
|
Media
|
Types
|
Continuous Paper, Gap, Black Mark, Punched Hole Label
|
|
Width
|
1”(25.4)-4.65”(118 mm), include the liner
|
|
|
Thickness
|
0.002”(60um)-0.01”(250um)
|
|
|
Label Roll Diameter
|
5”(127 mm) Max
|
|
|
Core Diameter
|
0.5”(12.7 mm), 1”(25.4 mm). 1.5”(38 mm)
|
|
|
Ribbon
|
Type
|
Wax,Wax/Resin,Resin
|
|
Width
|
1.18”(30 mm)-4.33”(110 mm)
|
|
|
Length
|
984′(300 m)
|
|
|
Core Diameter
|
1”(25.4 mm)
|
|
|
Software
|
Label Design Software
|
Bartender Ultralite
|
|
Driver
|
Windows 7/8/8.1/10, Windows Server 2008/2012/2016, Linux, MacOS(or macOS)
|
|
|
Resident Fonts
|
Bitmap fonts
|
6, 8, 12, 16, 32, OCR A & B. 90°, 180°, 270° rotatable and 10 times expandable in horizontal and vertical directions
|
|
TTF fonts
|
Monotype CG Triumvirate™. 0°, 90°, 180°, 270° rotatable
|
|
|
Download Fonts
|
Bitmap fonts
|
90°, 180°, 270° rotatable and 10 times expandable in horizontal and vertical directions
|
|
Asian fonts
|
16×16, 24×24. Traditional Chinese, Simplified Chinese, Japanese, Korean, 90∘,180∘,270∘, rotatable and 8 times expandable in
horizontal and vertical directions |
|
|
TTF fonts
|
90°, 180°, 270° rotatable
|
|
|
Barcodes
|
1D
|
Code 39, Code 93, EAN 8/13 (add on 2 & 5), UPC A/E (add on 2 & 5), I 2 of 5 & I 2 of 5 with Shipping Bearer Bars, Codabar, Code
128 (subset A, B, C), EAN 128, RPS 128, UCC 128, UCC/EAN-128 K-Mart, Random Weight, Post NET, ITF 14, China Postal Code, HIBC, MSI, Plessey, Telepen, FIM, GS1 DataBar, German Post Code, Planet 11 & 13 digit, Japanese Postnet, I 2 of 5 with human readable check digit, Standard 2 of 5, Industrial 2 of 5 , Logmars, Code 11, Code 49, Cadablock |
|
2D
|
PDF417, Data matrix code, Maxi Code, QR code, Micro PDF417, Micro QR code, Aztec code
|
|
|
Code Page
|
850, 852, 437, 860, 863, 865, 857,861, 862, 855, 866, 737, 851, 869, WINDOWS 1250, 1251, 1252, 1253, 1254, 1255, 1257,UTF-8,
UTF-16BE, UTF-16LE,DBCS 932 (JIS), 936(GBK), 949 (Koran), 950(BIG5) |
|
|
Graphics
|
Resident graphic file types are BMP and PCX, other graphic formats are converted by the software download
|
|
|
Interfaces
|
Standard
|
USB Type B, Ethernet
|
|
Optional
|
Wi-Fi,Bluetooth
|
|
|
ControlPanel
|
Power switch button, FEED button, 2 indicating LEDs
|
|
|
LCD Display
|
N/A
|
|
|
RTC Function
|
N/A
|
|
|
Power Supply
|
External AC/DC switching power adapter, AC 100V-240V/DC 24V/2A/48W,Peak 5A
|
|
|
Environment
|
Operation
|
5 to 50℃@ humidity 25% to 85% non-condensing
|
|
Storage
|
-40 to 60℃@ humidity 10% to 90% non-condensing
|
|
|
Physical Characteristic
|
Dimension(L×H×W)
|
308×250×180 mm
|
|
Weight
|
2.9 kg
|
|
|
Options & Accessory
|
Peeler Module, Cutter Module, External Label Roll Holder
|
|
|
Agency Approval
|
CE EMC(55022 Class B), FCC EMC(Cless A), CCC, RoHS
|
|
