IDPRT HN-1308SR/HN-1358SR 2D QR code Handheld Barcode Scanner
Plug-and-play hanheld scanner
Supports POS systems such as Android, Windows, and MAC
Full barcode scanning
Supports both 1D and 2D barcode scanning
Multi-national keyboards and character output
Supports 84 national keyboards and characters from Chinese, Japanese, Korean, and Thai
Bluetooth handheld barcode scanner version
Wireless Bluetooth scanner version supports wireless communication up to 10 meters
Full range of optional accessories
Optional accessories include serial cables, adapters, stands, and Bluetooth dongles
Retail Industry
Logistics and Warehousing Industry
Manufacturing Industry
Healthcare Industry
Government and Public Services Sector
| Item | Parameter |
| Sensor | CMOS |
| Pixels | 640*480 |
| Illuminatio | White light |
| Aiming | Red light |
| Symbologies | 2D: PDF417, QR Code, Data Matrix, HanXin, Maxicode , Postal Codes etc. |
| 1 D: Code128, UCC/EAN-1 28, AlM128, EAN-8, EAN-1 3, ISBN/ISSN,UPC-E,UPCA, Interleaved 2 of 5, ITF-6, ITF-4, Matrix 2 of 5, lndustriaI 25, Standard 25, Code39, Codabar, Code 93, Code11, Plessey, MSI-Plessey, RSS-14. RSS-Limited. RSS-Expand etc. | |
| Recognizing Precisio | ≥4mil |
| Depth of Field | EAN-13：30-200mm |
| QR(20mil): 20-150mm | |
| Barcode Sensibility | Pitch±45º |
| Tilt360º | |
| Skew±45º | |
| Field of view | Horizontal: 40°, vertical: 30° |
| Relative Contrast Value | ≥25% |
| Dimension(mm) | 100*68*165 |
| Weight | 135g |
| Interface Type | RJ-45 crystal head |
| Housing Material | PC+ABS |
| Notificatio | Buzzer, LED light |
| Interfaces | RS-232 serial interface |
| USB keyboard | |
| USB virtual serial interface | |
| Trigger Method | Keyboard recognition |
| Induction recognition | |
| Continuous recognitio | |
| Operating Voltage | 5VDC±10% |
| Operating Current | Standby: 50mA |
| Working: 230mA | |
| Working Temperature | -20–50°C |
| Storage Temperature | -40–70°C |
| Humidity | 5% to 95% (non-condensing) |
| ESD | ±4Kv Contact Discharge |
| ±8Kv Air Discharge | |
| Drop | 1.2m |
| Environmental Sealing | IP42 |
| Certifications | CE FCC |
