Cashino PDM-02 58mm Heldhand Thermal Receipt Barcode Printer Optional Bluetooth

The PDM-02 is lightweight portable printer, designed especially for those transaction applications where small size, fast printing and dependability while staying in budget are vital. Delivering the key features and communication methods, the PTP-II has the flexibility to meet the unique, industry-specific receipt printing and ease of use required to keep up with the mobile worker’s long and demanding shift.

Model Number：PDM-02

Print Method：Impact dot-matrix

Print Speed：5.5mm/s 1.2lps

Resolution：127dpi

Send email to us

Product Detail

parameter

Product Tags

Features

Compact design

Print carbon copy paper, which can be kept for a long time.

2000mAh li-ion battery - long lasting battery life.

With protective case, can reach 1.2 meter drop resistance. Also easily and comfortably carry the printer.

Wired and wireless interfaces: RS232/USB/Bluetooth.

Application

Food--Animal trace ability, Food safety

Meter Reading--Utilities charge

Insurance--Quick decide damage in car insurance field

Storage--Stock-taking,allocated and transfers in and out stock

Parking fee--Confirm the parking fee then charge

Logistics--Express transporation invoice,cargo delivery order

Mobile POS--Bus ticket;FMCG fast-moving consumer goods

Previous: Cashino KMP-200 2 inch Heldhand Thermal Receipt Label Printer Optional Bluetooth

Next:

Print Method	Impact dot-matrix
Print Speed	5.5mm/s 1.2lps
Dot Structure	240dots/mm
Print Width	48mm
Paper Width	57.5±0.5mm
Paper Type	Carbon copy paper
Paper Thickness	0.06-0.085mm
Paper Roll Diameter	Max. 40mm
Black Mark Location	Support
Character Set	ASCII(6×12,9×17,8×16), GBK(24×24)
Print Sequence	English, figure, symbol, Chinese, curve, graph,icon 24columns:144dots/line;40 columns:240 dots/line
Interface	RS232/USB+Bluetooth
Power supply	Battery: DC7.4V/2000mAh Rechargeable Li-ion batteryAdapter: DC 12V,0.8A Print Length for once: 15m(25%print density)18m(12.5% print density)
Dimension (WxLxH)	112x99x46mm
Weight	345g(with battery)
Accessories	Standard accessories: Li-ion battery, AC adapter, USB cable, paper roll, user manualOptional accessories: Serial cable/CD/Car charger/Protective Case
