Cashino CSN-C818 Thermal Barcode Receipt Printer Optional WIFI Auto Cutter
Support page mode(optional)
200 mm/sec low noise, high speed printing
Support full/partialcut, cover close cutting paper fuction
Compact body, exquisite design
Support anti-paper jam,platen position, black mark, paper end detection
Support 58/80/83mm adjustable paper width
Support 83mm Max Paper Roll Diameter
Retail store
Supermarket
Cinema
Restaurant
| Product model | C818 | |
| Printing | Print mode | Direct Thermal |
| Print width | 72mm(default)/48mm | |
| Print resolution | 203dpi(8dots/mm) | |
| Print speed max. | 200mm/s | |
| Storage | SRAM | 96K bytes |
| Flash | 256K bytes | |
| Paper | Type | Thermal paper roll |
| Width | 80mm | |
| Roll paper diameter（O.D） | 83mm | |
| Thickness | 0.055-0.09mm | |
| Character set | Font | Font A:12×24;Font B:9×17 GBK
:24×24 |
| Code page | 48 | |
| Barocde | 1D barocde | UPC-A, UPC-E, JAN/EAN8, JAN/EAN13, CODE39, ITF, CODEBAR, CODE128, CODE93 |
| 2D barocde | QRCode,PDF417 | |
| Interface | Standard | 4G+USB |
| Optional | 4G/WIFI/USB | |
| Sensor | Standard | Print head temperature Paper end Platen position detection |
| Cutter home position detection Black mark detection | ||
| Reliability | Cutting method | Full/Partial cut |
| Cutter life | 1,000,000cuts | |
| TPH life | 100km | |
| Power Adapter | AC | AC100V-240V 50/60Hz |
| DC | DC24V/2A | |
| Cash drawer control | DC24V 1A | |
| Dimensions (WxLxH)mm | 132x132x136 | |
| Weight | 0.9kg | |
| Emulation(Compatiable) | ESC/POS | |
| Software | Driver | Windows Driver,Linux Driver,OPOS Driver |
| SDK | Windows SDK,Android SDK Linux SDK | |
| Environment | Temperature | Operating:0°C~45°C |
| Storage:-20°C ~ 60°C | ||
| Humidity | Operating:20%RH~85%RH | |
| Storage:10%~90%RH | ||
