4 Inch Citizen CL-E321 Thermal Transfer Label Printer for Logistic Manufacturing
Unique design in white or black, with outstanding features and reliability
The new Citizen CL-E321 combines a unique and stylish design with outstanding performance and reliability, all in a compact, easy to use package. Designed for quick media and ribbon changes, the CL-E321 is equipped with wide 90 degree Hi-LiftTM opening mechanism, full connectivity and printer emulations. These features make it the ideal choice for applications ranging from high-end retail and healthcare, to logistics and courier services. Simple to setup and use, the CL-E321 ensures trouble-free operation , CL-E321 delivers speeds of 200mm/sec at 203dpi, with thermal transfer and direct thermal printing and it is available in black or white.
♦ Compact, stylish design with a small footprint
♦ Ethernet LAN, USB and Serial interfaces as standard
♦ Quick and easy ribbon change and media loading
♦ Paper width: Variable paper width - 1 inch (25.4 mm) – 4.6 inches (118.1 mm)
♦ Paper load: Hi-Lift™ mechanism and ClickClose™ closure
♦ Printing Speed: Ultra fast print out - up to 200mm per second (8 inches per second)
♦ Media support: Large media capacity - holds rolls up to 5 inches (127 mm)
♦ Paper thickness: Paper thickness up to 0.150mm
♦ Case colour: Available in black or white
♦ Media sensor: Adjustable media sensor, Black mark sensor
♦ Tear bar: Upper and lower tear bar
♦ Courier
♦ Logistic/Transport
♦ Manufacturing
♦ Pharmacy
♦ Warehousing
| Printing Technology | Thermal Transfer + Direct Thermal |
| Print Speed (maximum) | 8 inches per second (200 mm/s) |
| Print Width (maximum) | 4 inches (104 mm) |
| Media Width (min to max) | 1 – 4.6 inches (25 – 118 mm) |
| Media Thickness (min to max) | 63.5 to 190 μm |
| Media Sensor | Fully adjustable gap and reflective black mark |
| Media Length (min to max) | 0.25 to 100 inches (6.35 to 2540 mm) |
| Roll Size (max), Core Size | Inside diameter 5 inches (125 mm) Core size 1 inch (25mm) |
| Resolution | 203 dpi |
| Main Interface | Triple interface USB 2.0, RS-232 and 10/100 Ethernet |
| Case | Hi-Open™ industrial ABS case with safe close |
| Mechanism | Clamshell, easy-to-load, wide opening design |
| Control panel | One LED, Control key: FEED |
| Flash (Non-Volatile Memory) | 16 MB total, 4MB available for user |
| Drivers and software | Free-of-charge on CD with printer, including support for various platforms |
| Size (W x D x H) and Weight | 178 x 266 x 173 mm, 2.6 Kg |
| Warranty | 2 years on printer. 6 months or 50 Kms printhead |
| Emulations (Languages) | Datamax® DMX |
| Cross-Emulation™ – autoswitch between Zebra® and Datamax® emulations | |
| Zebra® ZPL2® | |
| CBI™ BASIC Interpreter | |
| Eltron® EPL2® | |
| Ribbon size | 2.6 inches (60 mm) maximum outside diameter. 300 metres length. 1 inch (25 mm core) |
| Ribbon winding & type | Ink side out. Wax, Wax/Resin or Resin Type |
| RAM (standard Memory) | 32MB total, 4 MB available for user |
| Barcodes | UCC/EAN,Composit Symb, GS1-Databar, QR Code,PDF 417 |
| CODABAR(NW-7), CODE128, CODE93, CODE39, Codabar, ITF | |
| EAN-8(JAN-8),EAN-13 (JAN-13),UPC-E,UPC-A,Code3of9 | |
| Media type | Roll or fanfold media; die-cut, continuous or perforated labels, tags, tickets. Inside or outside wound |
| EMC and safety standards | CE, TUV |
| UL,FCC,VCCI | |
| Number of Cuts | 300,000 cuts on media 0.06-0.15mm; 100,000 cuts 0.15-0.25mm |
| Pause after printing for tearing | Yes |
